Troubleshooting LG Error Code PE: What It Means & How to Fix

The PE error code on your LG top-load washer stands for a Pressure Sensor Error. This specifically means the main control board is unable to communicate with or receive a valid signal from the water level sensor (also known as a pressure switch). It is essentially your washer’s way of saying, “I have no idea how much water is in the tub, so I’m stopping for safety!”

When this happens, you might notice your washer refusing to start a cycle, or perhaps it fills up and then suddenly stops with a series of beeps. You might even hear the drain pump kicking in prematurely. I know how frustrating a pile of laundry can be, but take a deep breath! You don’t need a degree in engineering to fix this. It’s usually just a loose wire or a small plastic part that needs a quick swap. We can handle this together!

The Complete Solution: Step-by-Step Fix

Don’t worry, I’m going to walk you through this. Put on your DIY hat and let’s get that washer back in business!

Step 1: Safety First & The Hard Reset
Before touching any tools, unplug the washer from the wall outlet. Safety Warning: Never work on an appliance while it is plugged in! Once unplugged, press and hold the “Start/Pause” button for 5 seconds. This discharges any remaining electricity in the capacitors. Wait about 3 minutes, plug it back in, and try a cycle. Sometimes, a simple “reboot” clears a temporary glitch. If the PE code returns, move to Step 2.

Step 2: Accessing the Control Panel
You’ll need to get behind the “dashboard” of your washer. Using your Phillips head screwdriver, move to the back of the machine. You will typically see two or three screws holding the top plastic cover (the console) in place. Remove these carefully and set them aside in a bowl so they don’t roll away. Gently slide the console forward or lift it up (depending on your specific model) to reveal the internal components.

Step 3: Inspecting the Pressure Sensor and Wiring
Look for a small, round plastic piece (usually about the size of a silver dollar) with a thin plastic hose attached to the bottom and a wire plug at the top. This is your target. Unplug the wiring harness from the sensor. Inspect the metal pins inside the plug for any green or white “fuzz” (corrosion). If it looks clean, plug it back in firmly. A loose connection is the culprit 50% of the time!

Step 4: Checking the Pressure Tube
Pull the small plastic tube off the bottom of the sensor (you might need pliers to slide a small tension clip down first). Pro Tip: Blow gently into the tube. You should hear the water in the bottom of the tub gurgling. If it feels like you’re blowing into a clogged straw, the tube is blocked. You may need to trace the tube down to the tub and clear out any gunk or replace the tube if it’s cracked or pinched.

Step 5: Testing and Replacing the Sensor
If the wiring is tight and the tube is clear, the sensor itself is likely faulty. If you have a multimeter, you can check for resistance (ohms) across the pins, but for most DIYers, the easiest route is to simply replace the part. They are inexpensive and easy to find online using your washer’s model number. Simply pop the old one out, click the new one into the plastic housing, reconnect the hose, and plug in the wires.

Step 6: Reassembly and Testing
Place the console back into its slots and secure it with the screws you saved earlier. Plug the washer back into the wall. Run a “Speed Wash” or a “Rinse & Spin” cycle while empty to ensure the machine fills to the correct level and moves through the stages without the PE code appearing. You did it!

Why is my LG showing Error PE?

Understanding the “why” helps us ensure the “how” actually fixes the problem for good. Here are the four most common culprits behind this digital headache:

1. Loose or Corroded Wiring: LG washers vibrate—a lot. Over years of high-speed spinning, the delicate wiring harness that connects the pressure sensor to the main control board can jiggle loose. In some cases, moisture from the laundry room can cause slight corrosion on the metal pins, breaking the electrical connection.

2. Clogged Pressure Tube: There is a thin plastic tube that connects the bottom of the outer tub to the pressure sensor. As the tub fills, air is pushed up this tube to trigger the sensor. If this tube gets clogged with hair, lint, or undissolved detergent, the air can’t move, and the sensor thinks the tub is empty (or full) incorrectly.

3. Failed Pressure Sensor (The Switch): Like any electronic component, the sensor itself can simply burn out. This is often caused by localized voltage spikes or just general wear and tear of the internal diaphragm after thousands of cycles.

4. Control Board Malfunction: This is the rarest cause, but sometimes the “brain” of the washer fails to interpret the signal it’s getting. This is usually the last thing we check because it’s the most expensive part to replace.

Symptoms of the PE Error

Before we roll up our sleeves, let’s make sure we are looking at a classic PE error situation. Your LG washer is very communicative, and besides the flashing “PE” on the digital display, you might notice these physical signs:

• The Infinite Fill: The washer starts filling with water but never stops to begin the wash cycle, eventually triggering the error as a flood-prevention measure.
• The Dead Start: You press “Start,” you hear a few clicks, and instead of water rushing in, the machine immediately beeps and displays the error code.
• Mid-Cycle Stoppage: The washer might drain perfectly after a wash but fail to move into the rinse cycle because it can’t verify the tub is empty.
• Erratic Water Levels: You might notice the water levels are much higher or lower than the load size you actually selected.

How to Prevent Error PE

Once you’ve fixed the issue, let’s make sure it doesn’t come back to haunt you. Here are my mentor tips for a healthy washer:

• Use High-Efficiency (HE) Detergent: Standard detergent creates too many suds. These suds can actually enter the pressure tube, dry out, and create a “crusty” blockage that leads to PE errors. Always use the recommended amount of HE soap.
• Install a Surge Protector: Since the pressure sensor is a sensitive electronic component, it can be fried by power surges. A dedicated appliance surge protector is a small investment that saves big money.
• Level the Machine: Excessive vibration loosens wires. Use a bubble level to ensure all four feet of your washer are firmly on the ground. This reduces the “shaking” that causes the sensor’s wiring harness to wiggle free over time.

Frequently Asked Questions

Q: Can I use my washer while it has the PE error?
A: No. The machine is designed to lock out all functions when a PE error is detected. This is a safety feature to prevent the tub from overflowing and flooding your home, as the machine cannot verify how much water is inside.

Q: Is the pressure sensor the same as the inlet valve?
A: No. The inlet valve is what lets water into the machine (the “faucet”). The pressure sensor is the “measuring cup” that tells the machine when to turn that faucet off. If your machine won’t stop filling, the sensor is usually the problem, not the valve.

Q: How do I find the right replacement part?
A: Open the lid of your washer and look for a sticker on the frame or the back of the machine. This will have your Model Number (e.g., WT7100CW). Search for that model number plus “pressure switch” or “water level sensor” on a reputable parts website to ensure you get the exact match for your LG unit.
