Canon Pixma Error 1405 occurs when your printer experiences a communication failure with the print head’s internal memory chip. Specifically, it means the Electrically Erasable Programmable Read-Only Memory (EEPROM) on the print head cannot be recognized or read by the printer’s logic board, effectively causing an “identity crisis” for your device.
⚠️ Pro Tip: Verify Technical Specs
Working with electricity is dangerous. We strongly recommend downloading the official guide.
If you’ve been met with a stubborn flashing light or a sudden halt in your printing project, I know exactly how frustrating that feels! You might notice the printer carriage moving sluggishly, or perhaps you’re hearing the mechanical whirring of a machine that wants to work but just can’t quite get there. Don’t worry, my friend—you haven’t turned your printer into a paperweight just yet. Most of the time, this is simply a case of “dirty ears” (blocked electronic contacts) or a minor digital hiccup that we can solve together with a little patience and a steady hand. Let’s get your Pixma back to its happy, productive self!
| Metric | Details |
|---|---|
| Difficulty | Moderate (Requires steady hands) |
| Estimated Time | 20–30 Minutes |
| Tools Needed | 90%+ Isopropyl Alcohol, Lint-free cloth (or coffee filter), Q-tips, Latex/Nitrile gloves |
| Estimated Cost | $0 – $15 (unless print head replacement is required) |
Symptoms
Identifying Error 1405 is usually straightforward, but the printer often gives you several physical and visual clues before it completely locks up. Here is what you should look for:
- The LCD Display: Your printer’s screen will explicitly show the text “Error Code 1405” accompanied by a message stating “The print head cannot be recognized” or “The type of print head is incorrect.”
- Flashing Indicator Lights: If your model doesn’t have a screen, look at the Alarm/Resume light (the orange or amber LED). It will typically flash in a repeating cycle of 5 flashes, followed by a brief pause.
- Mechanical Stall: When you open the top cover, the print head carriage might move to the center replacement position but may shake slightly or refuse to move back to its “home” dock after you close the lid.
- Computer Pop-ups: On your PC or Mac, the Canon Status Monitor utility will trigger a window with a yellow exclamation mark, preventing any print jobs from entering the queue.
Technical Explanation of the Fault
Technical Explanation of the Fault
To fix the problem, we first need to understand why the brain of your printer is confused. The Error 1405 is rarely a random software bug; it is almost always rooted in the physical connection between the printer’s motherboard and the print head assembly.
1. Oxidation and Contamination: Over time, microscopic droplets of ink mist can settle on the gold-plated contact pads located on the back of the print head. Because ink is water-based and contains various chemicals, it can cause oxidation. This creates a thin, invisible film that acts as an insulator, preventing the low-voltage signals from the EEPROM chip from reaching the printer’s sensors.
2. Voltage Spikes and Static: Printers are sensitive electronic devices. A sudden power surge or even a build-up of static electricity (common in dry environments) can “scramble” the data being sent from the print head. This leads the printer to believe the print head is either missing or belongs to a different model entirely.
3. Physical Misalignment: The print head is held in place by a locking lever. If this lever isn’t seated perfectly, or if the ink cartridges aren’t snapped in with the correct pressure, the contact pins inside the carriage might not be making full contact with the gold pads. Even a fraction of a millimeter of space can trigger the 1405 error.
4. Component Wear and Tear: Like all electronics, the EEPROM chip has a limited lifespan. Years of heat from the printing process can eventually cause the solder joints on the chip to fail, leading to a permanent electronic fault that cleaning cannot fix.
Comprehensive Repair Guide
Comprehensive Repair Guide
Alright, let’s roll up our sleeves! Follow these steps carefully. Remember: we are dealing with sensitive electronics, so “gentle” is our keyword today.
Step 1: The “Deep” Power Cycle
Before touching any hardware, let’s try to clear the printer’s temporary memory. Turn the printer on, and while it’s running, pull the power cord directly from the back of the unit. Wait for at least 60 seconds to allow the capacitors on the motherboard to fully discharge. Plug it back in and see if the error clears. If not, proceed to Step 2.
Step 2: Accessing and Removing the Print Head
Open the printer’s main cover. Wait for the carriage to slide to the center. Safety Warning: Do not try to force the carriage to move with your hands while the printer is off; only move it when the printer is powered. Once in the center, remove all individual ink tanks and set them upright on a piece of paper to avoid leaks. Locate the grey locking lever on the side of the carriage and lift it up. You can now gently lift the print head assembly out of the printer.
Step 3: Cleaning the Gold Contact Pads
Look at the back of the print head (the side that faces the back of the printer). You will see a series of small, gold-plated squares. Dip a Q-tip or a lint-free cloth into your Isopropyl alcohol. Crucial: Use 90% or higher alcohol, as lower percentages contain more water which takes longer to dry. Gently wipe the gold pads until they are shiny. If you see green or black residue on the cloth, that was your culprit!
Step 4: Cleaning the Internal Carriage Pins
Now, look inside the printer where the print head usually sits. You will see small, springy gold pins. These are very delicate! Use a dry Q-tip or one very lightly dampened with alcohol to gently brush any dust or ink splashes off these pins. Do not use a “scrubbing” motion, as you might bend a pin, which would require a professional repair.
Step 5: Drying and Reinstallation
Let the print head air dry for about 5 minutes. Even though alcohol evaporates quickly, we want to be 100% sure. Place the print head back into the carriage, lower the grey locking lever, and reinsert your ink cartridges. Ensure each cartridge “clicks” firmly into place. Close the cover and let the printer perform its startup initialization.
Step 6: The Semi-Full Reset (If Error Persists)
If the 1405 code is still there, try this: With the printer ON, open the cover. Remove the ink and print head. Close the cover. The printer will complain that the print head is missing. Unplug the power. Wait 30 seconds. Plug it back in, open the cover, and reinstall the components. This often forces the printer to “re-discover” the hardware.
How to Prevent Error 1405
Now that we’ve hopefully cleared that error, let’s make sure it doesn’t come back to haunt you! Here are three tips to keep your Pixma in tip-top shape:
1. Use a High-Quality Surge Protector: Since Error 1405 is often caused by EEPROM data corruption, protecting your printer from “dirty” power is vital. Plug your printer into a dedicated surge protector rather than directly into a wall outlet to prevent voltage spikes from scrambling the print head’s logic.
2. Perform Monthly “Contact Maintenance”: You don’t have to wait for an error to clean! Every few months, when you are changing an ink cartridge, take ten seconds to wipe the gold contacts on the back of the print head with a dry, lint-free cloth. This prevents the buildup of ink mist before it can oxidize.
3. Keep the Printer “Sleepy,” Not “Dead”: Instead of turning the printer completely off at the power strip every night, use the printer’s own “Power” button to put it into Standby mode. This allows the printer to perform tiny, periodic maintenance cycles that keep the ink from drying out and prevents static buildup on the internal circuits.
FAQ
Frequently Asked Questions
Q: I cleaned the contacts three times and the error is still there. Is my printer broken?
A: If thorough cleaning doesn’t work, it usually means the EEPROM chip inside the print head has suffered a hardware failure. In this case, you don’t need a new printer, but you will likely need a replacement print head (Model numbers vary, e.g., QY6-0082). Compare the cost of a new print head versus a new printer before buying!
Q: Can I use Windex or water instead of Isopropyl Alcohol?
A: I strongly advise against it! Windex contains ammonia and other chemicals that can corrode the delicate gold plating over time. Tap water contains minerals that can leave a conductive residue, potentially short-circuiting the print head. Stick to 90%+ Isopropyl alcohol for the safest results.
Q: Will resetting my computer fix Error 1405?
A: Unfortunately, no. Because Error 1405 is a hardware-level communication failure between the printer’s “brain” and the “print head,” the issue exists entirely within the printer itself. Reinstalling drivers or rebooting your PC won’t solve the physical connection issue on the device.
