KitchenAid Refrigerator Error EE Solved: Detailed DIY Repair

The **KitchenAid Error Code EE** is a specific diagnostic fault indicating that the ice maker’s thermistor (temperature sensor) circuit is either “open” or “shorted.” Essentially, the refrigerator’s main control board has lost its ability to accurately monitor the temperature of the ice-making hardware, leading to a complete halt of the ice production cycle to prevent mechanical damage.

While seeing a flashing error on your premium appliance can be frustrating, this is a common issue typically rooted in sensor fatigue or wiring harness stress. You may notice your ice bucket is empty, a faint clicking sound as the unit attempts to cycle, or water that remains chilled but never freezes into cubes. Rest assured, this is a repairable condition that often doesn’t require a full refrigerator replacement, and with the right technical approach, we can restore your appliance to peak performance.

How to Fix KitchenAid Error EE (Step-by-Step)

1. Safety First and Power Discharge:

   Before performing any mechanical intervention, unplug the refrigerator from the wall outlet. Simply turning it off via the display is insufficient, as the control board remains energized. Wait approximately 5 minutes for the capacitors on the board to discharge. Warning: High voltage components are present near the compressor and control board areas.

   ⚡ Safety First: Read Before Repairing

   Working with electricity is dangerous. We strongly recommend downloading the official guide.


   📂 View KitchenAid ee Specs


2. Accessing the Ice Maker Assembly:

   Open the freezer or the dedicated ice compartment door. Use your Phillips head screwdriver to remove the mounting screws securing the ice maker cover. Carefully pull the cover forward. You will see a wiring harness clipped to the side or top. Use your needle-nose pliers to gently depress the locking tab on the plastic Molex connector and disconnect the ice maker from the refrigerator’s main harness.

3. Visual Inspection of the Wiring:

   Examine the wires leading from the sensor (usually tucked near the bottom of the ice mold) to the plug. Look for any signs of blackening, fraying, or green corrosion on the pins. If the wires appear pinched near the hinge, you have found your culprit. If the wiring looks pristine, the fault lies within the sensor itself.

4. Performing the Resistance Test (Multimeter Required):

   Set your digital multimeter to the 20k or 40k Ohm setting. Place your probes on the two wires dedicated to the thermistor (refer to the wiring schematic usually located on the back of the fridge or inside the kick plate). At room temperature (approx. 77°F), you should see a reading of about 10k Ohms. If the meter reads “1” or “OL,” the sensor is Open. If it reads “0.00,” it is Shorted. In either case, the thermistor must be replaced.

5. Replacing the Sensor or Ice Maker Unit:

   On many modern KitchenAid models, the thermistor is integrated into the ice maker wire harness and is not sold as a standalone part. In this scenario, you must replace the entire ice maker assembly. Unscrew the mounting bolts (usually two at the top), slide the old unit out, and slide the new unit in. Ensure the water fill tube is properly aligned with the entry port on the new ice maker to avoid leaks.

6. Reassembly and System Reset:

   Plug the wire harness back in until you hear a “click.” Reinstall the covers and screws. Restore power to the unit. To clear the “EE” code, you may need to enter the service mode (pressing ‘Select’ and ‘Water’ simultaneously on some models) or simply wait 10 minutes for the control board to run its Power-On Self-Test (POST). If the code persists, the main control board may require a hard reset by unplugging for an additional 20 minutes.

What Triggers this Code?

What Triggers this Code? (In-Depth Diagnosis)

The “EE” code is a binary diagnostic: the control board expects a specific range of electrical resistance (measured in Ohms) from the thermistor. When that resistance falls to zero (Short) or rises to infinity (Open), the logic gate triggers the error. Here is why that happens:

1. Thermistor Internal Failure (Wear and Tear):
The thermistor is a Negative Temperature Coefficient (NTC) resistor. Over years of thermal cycling—moving from freezing temperatures to the slightly warmer harvest temperatures—the internal semi-conductor material can crack. This creates an “open” circuit where electricity can no longer flow, or a “shorted” circuit where the signal bypasses the resistor entirely.

2. Wire Harness Fatigue:
In KitchenAid French Door models, the ice maker is often located in the left-hand door. The wiring harness must pass through the door hinge. Every time you open and close the refrigerator door, those wires flex. Over time, the thin gauge copper wires dedicated to the sensor circuit can snap inside the insulation, leading to an intermittent or permanent “EE” code.

3. Moisture Ingress and Corrosion:
The ice room is a high-humidity environment. If the protective resin coating on the sensor or the pins in the plastic connector blocks fails, moisture can enter. This creates a “bridge” between terminals, causing a short circuit. This is often the result of a clogged defrost drain or a poorly sealed ice room door.

4. Control Board Logic Faults:
While less common, the “EE” code can be triggered by a failure in the Analog-to-Digital (A/D) converter on the main control board. If the board’s internal “pull-up” resistor fails, it will report an “EE” error even if the sensor itself is perfectly healthy.

Symptoms of a KitchenAid EE Error State

As a senior engineer, I have observed that the “EE” code rarely appears in isolation. It is usually accompanied by a specific set of mechanical failures that signal the control board’s inability to read the thermistor. Look for the following signs:

• Complete Cessation of Ice Production: Because the control board cannot verify if the ice mold is cold enough to harvest, it will not trigger the ejector arms or the water fill valve.
• Flashing Control Panel: The “EE” code will typically blink on the dispenser display, often disabling other dispenser functions like water delivery as a safety precaution.
• Audible Clicking: You may hear the ice maker’s internal motor attempting to “home” itself or the relay on the control board clicking repeatedly as it tries to pulse a signal to a non-responsive sensor.
• Frost Accumulation: In some cases, if the sensor is “shorted” (reading incorrectly low), the unit may over-freeze the ice room, leading to heavy frost buildup around the ice maker’s air vents.
• Warm Ice Compartment: Conversely, if the circuit is “open,” the refrigerator might stop sending cooling to the ice room entirely, resulting in lukewarm temperatures in the door-mounted bin.

How to Prevent Error EE from Recurring

To ensure your ice maker remains functional and to prevent the thermistor from failing prematurely, follow these engineering-standard maintenance tips:

• Maintain Optimal Freezer Airflow: Ensure that food items are not blocking the air vents in the freezer or the ice compartment. Poor airflow causes the ice maker to work harder and cycle more frequently, which stresses the thermistor through excessive thermal expansion and contraction.
• Check Door Gaskets Regularly: If the door seal around the ice compartment is leaking, warm/moist air will enter. This leads to ice bridging and moisture buildup on the sensor wires. Clean your gaskets with warm soapy water every six months and check for any “puckering” or gaps.
• Use a High-Quality Surge Protector: The control board reads the thermistor based on very low-voltage signals. A power surge can damage the sensitive resistors on the control board that interpret these signals, leading to “ghost” EE codes. A dedicated appliance surge protector is a wise investment for high-end KitchenAid models.

Frequently Asked Questions

Q: Can I manually reset the EE code without replacing parts?
A: You can attempt a “hard reset” by disconnecting power for 10-20 minutes. If the code was triggered by a temporary glitch or a momentary voltage spike, this might clear it. However, if the “EE” code returns within 24 hours, it confirms a physical hardware failure in the thermistor circuit that requires repair.

Q: Is it possible to replace just the sensor instead of the whole ice maker?
A: On older KitchenAid models, the thermistor was a separate clip-on component. On most modern “In-Door-Ice” models, the sensor is molded into the harness or the tray itself. While some DIYers “splice” in a generic 10k Ohm NTC thermistor, as an engineer, I recommend replacing the official assembly to ensure the resistance-temperature curve matches the control board’s factory calibration.

Q: My water dispenser works, but the display still says EE. Why?
A: The refrigerator’s logic treats the ice maker and the water dispenser as separate sub-systems. The “EE” code specifically locks out the ice-making harvest cycle. Your water dispenser may still work because its solenoid valve is not dependent on the ice mold’s temperature. However, on some firmware versions, the board may disable the entire UI until the fault is cleared.
