If you are seeing this code, you are likely experiencing a furnace that blows cold air, a blower motor that runs incessantly without producing heat, or a unit that “short cycles” (turns on and off rapidly). While it sounds alarming, this is a protective measure. With a systematic approach, most homeowners can diagnose and often resolve the underlying airflow or electrical issues causing this fault.
Symptoms of Carrier Error 33
Identifying Error 33 goes beyond just reading the LED light on the furnace control board. You will typically notice several distinct physical signs that the limit circuit has been tripped:
🛠️ Warning: Check Manual First
For your safety and to avoid voiding the warranty, please check the official docs.
- The Flash Code: When you look through the sight glass on the lower furnace panel, you will see the status LED blinking 3 short flashes, followed by a brief pause, and then 3 more short flashes (Code 33).
- Continuous Blower Operation: The large blower fan may run constantly, even if the thermostat is set to “Auto” and the temperature is satisfied. This is the furnace’s “cool down” mode.
- Lack of Combustion: You may hear the inducer motor (the small fan) start, and perhaps see the igniter glow, but the flames will either fail to light or extinguish almost immediately.
- Short Cycling: The furnace may run for 2 to 5 minutes, reach a certain internal temperature, and then abruptly shut down the burners before the house is warm.
How to Fix Carrier Error 33 (Step-by-Step)
- Perform a Hard Reset and Power Down:
Before touching any components, turn the thermostat to the “Off” position. Go to your electrical breaker panel and switch off the circuit breaker dedicated to the furnace. Safety Warning: Furnaces contain high-voltage components and moving parts. Never attempt repairs with the power engaged.
- Inspect and Replace the Air Filter:
Locate your filter rack. Remove the filter and hold it up to a light source. If you cannot see light through it, it is restricted. A common “pro tip” to diagnose Error 33 is to briefly run the furnace without the filter; if the error disappears, the filter was the culprit. Replace it with a new, high-flow pleated filter.
- Verify Ductwork Integrity:
Walk through your home and ensure at least 75-80% of your supply vents are fully open. Check that large area rugs or sofas are not blocking the return air intakes. Obstructed returns are just as damaging to airflow as a dirty filter.
- Access the High-Limit Switch:
Using your Phillips head screwdriver or 1/4″ nut driver, remove the upper access panel of the furnace. The limit switch is usually located on the center of the interior bulkhead, positioned just above the burners. It is a small, circular or rectangular component with two wires (usually orange or red) attached to it.
- Test the Switch for Continuity:
Pull the two wire connectors off the switch terminals. Set your digital multimeter to the “Ohms” (Ω) or Continuity setting. Place one probe on each terminal of the switch. If the furnace is cool, the meter should read 0 or show a “Beep,” indicating the circuit is closed. If the meter reads “OL” (Open Link) while the furnace is cold, the switch is defective and must be replaced.
- Inspect the Secondary Heat Exchanger (Advanced):
If the filter is clean and the switch tests fine, use a flashlight to look at the blower wheels. If the fins are coated in dust, they cannot move air efficiently. Use a vacuum and a soft brush to clean the blower blades. Safety Warning: Ensure the blower has completely stopped spinning before reaching inside.
- Restore Power and Test:
Reinstall the panels (the furnace will not run if the door switch is not depressed). Restore power at the breaker and set the thermostat to “Heat.” Observe the sequence of operation to ensure the burners stay lit for a full cycle.
| Metric | Specification |
|---|---|
| Difficulty Level | Intermediate (Requires basic electrical testing) |
| Estimated Time | 45 – 90 Minutes |
| Tools Needed | Digital Multimeter, Phillips Head Screwdriver, 1/4″ Nut Driver, Vacuum with Brush Attachment |
| Estimated Cost | $0 (Cleaning) to $85 (Replacement Switch) |
Detailed Diagnosis: Root Causes
To fix Error 33, you must understand that the limit switch is usually doing its job—it is reacting to a problem, not necessarily failing itself. Here are the primary causes:
1. Restricted Airflow (The #1 Cause):
The most common reason for a limit circuit to open is that the heat exchanger is getting too hot because there isn’t enough cool air blowing over it. This is typically due to a heavily clogged 1-inch or media filter. When airflow is restricted, the heat builds up locally around the burners, exceeding the switch’s temperature threshold (usually between 140°F and 180°F depending on the model).
2. Mechanical Wear of the Limit Switch:
High-limit switches are “bimetal” discs that warp to break a connection when heated. Over years of operation, especially if the furnace has frequently overheated in the past, the metal can become “fatigued.” This causes the switch to trip at a much lower temperature than its factory rating, or sometimes fail in the “open” position permanently.
3. Closed or Blocked Supply Vents:
If too many supply registers are closed in the house to “save energy,” the static pressure inside the furnace rises, and airflow drops. Similarly, furniture or rugs covering return air grilles starve the furnace of the air it needs to keep the heat exchanger cool.
4. Failed Blower Motor or Capacitor:
If the blower motor is spinning too slowly or failing to start due to a bad capacitor, the heat produced by the burners has nowhere to go. This leads to an immediate spike in temperature, triggering the limit circuit as a fire prevention measure.
How to Prevent Error 33
Preventing a Limit Circuit Fault is largely about maintaining consistent, unobstructed airflow. Follow these professional maintenance tips:
- Adopt a Strict Filter Schedule: Do not rely on “3-month” ratings. If you have pets or live in a dusty climate, check your filter every 30 days. High-MERV filters (MERV 11-13) are great for air quality but provide higher resistance; consider a MERV 8 for better furnace longevity.
- Annual Static Pressure Check: During your yearly professional tune-up, ask the technician to perform a static pressure test. This ensures your ductwork is sized correctly for your furnace’s blower capacity, preventing “silent” overheating.
- Clean the Evaporator Coil: If you have central air conditioning, the A-coil sits on top of your furnace. If this coil gets plugged with dust, it acts like a wall to the furnace’s airflow. Have this coil professionally cleaned every 3-5 years to ensure the air can pass freely into the supply ducts.
Frequently Asked Questions
Can I bypass the limit switch to get heat tonight?
No. You should never bypass a safety limit switch. This switch is the only thing preventing your heat exchanger from melting or causing a house fire. If the switch is tripping, there is a dangerous heat condition that must be addressed.
Does Error 33 mean I need a new furnace?
Rarely. Error 33 is almost always a maintenance issue (airflow) or a component issue (the switch itself). However, if the switch is tripping because the heat exchanger is cracked or “sooted up,” a replacement may be discussed, but this is the exception, not the rule.
How much does a professional charge to fix Error 33?
If the issue is just a dirty filter, you will likely pay a standard service call fee ($75–$150). If the limit switch needs replacement, the total cost typically ranges from $150 to $300, including parts and labor.
