Error 93 on a Brother laser printer signifies a Paper Feed Sensor Error. This technical fault occurs when the internal logic board detects that the paper feed sensor (or registration sensor) has failed to trigger, is stuck in the “on” position, or is communicating an inconsistent voltage signal during the initial startup or printing sequence.
⚡ Warning: Check Manual First
Don’t guess the wiring. Get the official PDF to see the exact schematics.
You might be experiencing frustrating “self-diagnosis” loops where the printer restarts repeatedly, or perhaps you hear the mechanical grinding of rollers spinning without actually picking up paper. In some cases, the printer may simply sit silent while a red “Error” light flashes ominously. While it sounds technical, don’t worry—this is a mechanical and electronic hurdle that can almost always be fixed with patience and a few basic tools, saving you a costly trip to the repair shop.
Symptoms
Identifying Error 93 early can prevent further mechanical wear on the printer’s drive gears. Look for these specific physical and operational signs:
- The LCD Display: The printer screen explicitly shows “Error 93” or “Self-Diagnostic: Will Automatically Restart within 15 Minutes,” but the restart never clears the fault.
- Physical Paper Jams: You consistently find paper crumpled near the registration roller or stuck just as it leaves the paper tray, even if the paper itself is fresh and dry.
- Mechanical Clicking: Upon powering on, you hear a rhythmic clicking or snapping sound as the printer attempts to reset the sensor lever, but fails.
- Solid Red Status LED: On models without a screen, the “Error” LED stays solid red, and the printer refuses to acknowledge any print commands from the computer.
The Complete Solution
Follow these steps in order. Safety Warning: Always unplug the power cord and wait at least 10 minutes for the fuser unit to cool down and for high-voltage capacitors to discharge before opening the internal chassis.
- Initial Power Cycle and Hard Reset:
Begin by turning the printer off using the power button, then unplugging it from the wall. While unplugged, press and hold the “Go” or “Start” button for 15 seconds. This discharges the remaining electricity on the main board, which can sometimes clear a “ghost” error stored in the volatile memory. Plug it back in after 2 minutes to see if the error persists. - Accessing the Paper Path and Registration Area:
Open the front cover and remove the toner cartridge and drum unit assembly. Set them aside in a dark place (cover them with a cloth to prevent light damage to the drum). Use your Phillips head screwdriver to remove the rear access panel and, if necessary, the side plastic shrouds. You are looking for a small, black plastic “finger” located near the metal registration rollers—this is the paper feed sensor actuator. - Manual Inspection and Cleaning:
Check if the sensor actuator arm moves freely. Flick it gently with your finger; it should snap back instantly. If it feels sluggish, use canned air to blow out the housing. Following this, dampen a lint-free swab with isopropyl alcohol and clean the pivot point of the arm and the optical gap of the sensor. Warning: Do not use excessive alcohol, as it can degrade certain plastics over time. - Checking for Structural Integrity:
Examine the tiny spring attached to the sensor arm. If it is detached, use a pair of needle-nose pliers or a dental pick to re-seat it onto the plastic post. If the arm itself is bent or shows white “stress marks” in the plastic, it must be replaced, as it will continue to snag on the paper path. - Advanced Multimeter Diagnostics:
If the error remains, locate the 3-wire harness connecting the sensor to the main PCB. Set your multimeter to DC Voltage. With the printer powered on (be extremely careful of moving parts), measure the voltage between the ground and signal pins. It should toggle (typically between 0V and 3.3V or 5V) when you manually move the sensor arm. If the voltage stays constant regardless of the arm’s position, the photo-interrupter is electronically dead and the sensor board requires replacement.
- Repair Difficulty: Moderate (Requires some disassembly and delicate handling of plastic components).
- Estimated Time: 45 to 60 minutes.
- Tools Needed: Phillips Head Screwdriver (#2), Canned Air or a specialized electronics vacuum, 90% Isopropyl Alcohol with lint-free swabs, and a Digital Multimeter (for advanced continuity testing).
- Estimated Cost: $0 (if just cleaning) to $25 (if a replacement sensor assembly is required).
Technical Explanation of the Fault
To fix Error 93, one must understand that Brother printers rely on a series of photo-interrupter sensors. These consist of a small plastic “actuator” arm and an infrared beam. When paper passes, it pushes the arm, breaking the beam and telling the printer where the paper is. Failure occurs for several nuanced reasons:
1. Accumulation of Paper Dust and Toner Carbon: Laser printers are inherently “dirty” environments. Over thousands of pages, microscopic paper fibers and stray toner dust settle into the pivot point of the sensor arm. This creates friction, causing the arm to stick in the “triggered” position. The logic board sees the beam is broken before the print job starts and throws Error 93 as a safety precaution.
2. Sensor Spring Fatigue or Displacement: Each sensor arm is returned to its neutral position by a tiny, high-tension spring. If a user has recently cleared a “hard” paper jam by pulling the paper backward, that spring can become elongated or unhooked. Without the spring’s return force, the sensor cannot reset for the next page.
3. Opto-Electronic Failure: Occasionally, the infrared LED or the phototransistor inside the sensor housing fails due to voltage spikes or simple component aging. If the sensor cannot “see” its own light, the printer assumes a mechanical blockage exists, regardless of the physical state of the paper path.
How to Prevent Error 93
Once you have restored your printer to working order, follow these maintenance protocols to ensure the sensor remains functional:
- Use High-Quality Paper: Cheap, high-acid paper sheds significantly more “paper lint.” This lint is the primary cause of sensor sticking. Switching to a “99% dust-free” rated paper can extend sensor life by years.
- Regular Interior Vacuuming: Every time you replace a toner cartridge, use a specialized electronics vacuum (or a gentle puff of air) to clear the registration area. Do not use a standard household vacuum, as the static electricity can fry the logic board.
- Correct Jam Removal Technique: Never pull paper out through the back of the printer if it is stuck in the feed area. Always pull paper in the direction of the normal paper path to avoid over-extending the sensor springs.
Frequently Asked Questions
Q: Can a firmware update fix Error 93?
A: While Error 93 is primarily mechanical, Brother occasionally releases firmware updates that adjust the “timing tolerances” of the sensors. If your sensor is slightly sluggish but not broken, a firmware update via the Brother Support website may allow the printer to operate within a wider margin of error.
Q: I cleaned the sensor but the error is still there. What now?
A: If cleaning fails, the issue is likely a “blown” sensor or a failure on the Main Engine Board. Inspect the wire harness for any pinched or frayed wires that might have occurred during a previous repair or a particularly violent paper jam. If the wires are intact, the sensor assembly (usually part number starting with “LU” or “LY”) needs replacement.
Q: Is Error 93 the same as a “No Paper” error?
A: No. A “No Paper” error means the tray sensor doesn’t feel weight or see paper. Error 93 is specifically about the *timing* and *movement* of the paper as it transitions from the tray into the internal printing mechanism. It is a more complex mechanical failure than simply being out of paper.
